Name: TEKA BI CHIMNEY 90 CM Up to 740 m³/h extraction capacity PERFECTA4 DLH 985 T
SKU: PERFECTA4 DLH 985 T
Availability: InStock

TEKA BI CHIMNEY 90 CM Up to 740 m³/h extraction capacity PERFECTA4 DLH 985 T

BD237.000

Your hood always clean

Decorative filters with 12 layers ready to absorb up to 98% of grease and helping you to keep your hood clean. And you can wash the filters in the dishwasher.

Maximum efficiency with lower consumption

Our hoods have 4A Energy Class so will reduce your next electric bill significantly.

Extraction from any angle

Teka hoods have optimal absorption capacity by extraction to enjoy your kitchen free of smoke and odors.

Ambient lighting: adjust the ligh temperature and intensity to your kitchen

LED lighting bars is our best tool to provide light to a bigger area over the cooking zone, and being more efficient and environmentally friendly at the same time.

Technical details

Decorative horizontal hood
Electronic control with display
EcoPower motor
3 speeds + 1 intensive
Free Outlet exhaust capacity (m3/h): 795
Intensive speed exhaust capacity (m3/h):740
Max speed exhaust capacity (m3/h): 586
Min speed exhaust capacity (m3/h): 306
Intensive speed sound level (dBA): 60
Max speed sound level (dBA): 55
Min speed sound level (dBA): 54
1 LED lamp
3 Stainless Steel filters with 12 layers
Stop delay timer
Filter saturation indicator
Operating pilot light
Exchangeable front panel
Anti-return valve included
Outlet reduction included

Interior measurements

Inner Height (mm): 955

General measures

Product height (mm): 670-1000
Product width (mm): 900
Product depth (mm): 480
Net weight (Kg): 15,33

Features

Certificates: CE; CB; Rohs
Ø Outlet (mm): 150
Type of inner light: LED
Inside light Consumption (W): 1 7
Plug type: Schuko plug
Power rate (V): 230
Frequency (Hz): 50
Total hood power (W): 287
Number of motors: 1
Motor power (W): 280
Air flow (Qmin) m3/h: 352
Air flow (Qmax): 651
Air flow (Qboost): 760

Accessories

Anti Return valve: Yes
Outlet reduction: Yes
Outlet extension: No
Optional Charcoal Filter: C1RTK
Regenerative charcoal filter: R1RTK
Conventional recirculation kit (opt) – w/tube cover: CFH 15200 L3C
Regenerative recirculation kit (opt) – w/tube cover: RFH 15200 L3C

Models

Number of filters: 3
Filter description: Stainless Steel filters MMX
Control panel: Touch Control (Glass Front) white display
Stop delay timer: Yes
Filter saturation indicator: Yes
Time clock: Yes
Number of speeds: 3+1
